No Virtual Desktop Infrastructure Software will be perfect enough to cover all the needs of a specific team. Though core features of Amazon WorkSpaces and Citrix Virtual Apps & Desktops are important you should also thoroughly study the integrations provided by a given software. In many cases you will already be using various kinds of B2B. Nutanix and Citrix technologies enable you to deploy 2,000 new Citrix virtual desktops in an existing site in under two hours on new hardware running in AWS. If you need to expand your existing Citrix deployment quickly, Nutanix Clusters will allow you to do so. When expanding a Citrix Virtual Apps and Desktops site, there are two options. Citrix recommends the CloudFormation template for creating Citrix ADC VPX instances on AWS. Citrix recommends you create three interfaces: one for management (NSIP), one for client-facing LB virtual server (VIP), and one for subnet IP (NSIP). Create an AWS Autoscale group. If you don’t have an existing Autoscaling configuration, you must.
Citrix is also providing a CloudFormation template for automated installation and configuration of Citrix XenDesktop® platforms for hosting desktop virtualization and mobile apps on AWS.
Leveraging AWS provides the ability to reallocate upfront costs of a large physical hardware infrastructure purchase into an on-demand operating expense model distributed over an extended timeframe. The instant availability of cloud-based resources, coupled with CloudFormation automation templates, dramatically reduces the implementation time previously allocated for procuring, racking and cabling physical servers. By delivering virtual desktops and applications through XenDesktop running on AWS, IT administrators are able to power a powerful desktop virtualization solution with a cost as low as one penny per hour per user for IaaS capacity. For details, see the whitepaper, Scalability and Economics of XenApp on Amazon Cloud.
The AWS-based approach provides advanced management and scalability, a rich multimedia experience over any network, and self-service applications with nearly universal endpoint device support ranging from desktops to laptops to tablets and smartphones. Session and application virtualization technologies make it easy for customers to centrally manage applications using any combination of local and hosted delivery to best fit their unique requirements. Desktop virtualization simplifies application management and brings unprecedented levels of scalability to increase cost savings and datacenter efficiency.
Enterprises are looking to clouds that can deliver cost-effective, enterprise-class platforms to power the applications that users need. Citrix helps IT deliver those applications via desktop and application solutions like Citrix XenDesktop. The attractiveness of a cloud-based desktop and application platform is driven by the ever-evolving demands of workforce growth, mobility and geographical disbursement.
I was recently afforded the unique opportunity to collaborate on a project to test capacity out of a Citrix XenApp on AWS deployment. The goal of the project was to independently determine the maximum user density for a few different EC2 instance types running XenApp 7.14.
EC2 instances are on-demand and elastic hosted server resources. Which means that they are provisioned dynamically within a pool of available resources, and with an OS you deploy on top. Amazon provides a variety of templates to easily install Windows, Linux or your other favorite OS. EC2 instances are broken down into a few varieties. They are optimized for storage, memory, compute or graphics. The designation before the name of the instances illustrates their configuration. G3 indicates graphics optimized instance third generation.
The other difference between instance type is the cost. If you are provisioning a 2vCPU 4GB of RAM machine the price per hour would be significantly less than that of a 16vCPU 64GB of RAM machine.
This would allow the customer to match the exact machine size to the purpose of their deployment, and optimize the amount of money they were spending on their hosted application solution.
Utilizing Login VSI’s virtual users I ran a predetermined user count against a Citrix XenApp deployment managed from Citrix Cloud.
For those of you not familiar Citrix Cloud is providing Citrix capabilities traditionally delivered on premise through a HTML web based user experience therefore installing a receiver is no longer required.
Some of the key components as they move into their cloud forward offerings are StoreFront / Netscaler and Studio.
StoreFront and NetScaler are completely managed now through a web page. This completely removes the administrator’s responsibilities of configuring hardware / software solutions for Citrix. You simply fire this up, attach it via their “Citrix Cloud Connector” and configure to start deploying your desktops or apps. It works completely flawlessly.
Studio is managed through the connector as well, and provides the Citrix HTML 5 receiver for management access through the Citrix Cloud web portal.
During my time working with it, it proved to be very flexible, easy to configure and reliable for all testing. I would recommend this to any administrator looking at future proofing their Citrix deployments. It is truly ready for market.
Some images below of the management interface:
There will be a management icon within your Citrix Cloud Dashboard. Select “XenApp and XenDesktop Service” “manage”
You will then go to the management interface for XenApp / XenDesktop; you have two options Creation and Delivery. Creation – Studio / Delivery – StoreFront / NetScaler:
Citrix Vs Aws
Management interface for Studio. Notice the Citrix Receiver icon in the middle. Studio is provided through the Citrix HTML 5 receiver. Interesting touch.
Management for Citrix NetScaler / StoreFront:
AWS Configuration for demonstration purposes:
Color coded
Delivery group configuration:
There is only one XenApp host in each delivery group. This is to determine the maximum amount of users for one M4.2XLarge instance backing the XenApp host. We are delivering Office 2016 applications, and the standard set of VSI Knowledge worker actions.
It is very easy to change the instance type in EC2. You simply select the “Instance” and change the “Instance Type” through the context menu.
It is very easy to change the instance type in EC2. You simply select the “Instance” and change the “Instance Type” through the context menu.
There are a variety of different configuration, which allows you to really get the most out of the testing. If you are aiming for user density numbers you can size it exactly. This allows you to pay for EXACTLY what you need as opposed to over provisioning. This will help drive the cost of VDI / SBC deployments down ultimately, and increase end user experience quality.
If you are sizing your images with Login VSI and backing them up with EC2 AWS instances you are getting an optimal user experience exactly sized right for your needs.
Information on instances: https://docs.aws.amazon.com/AWSEC2/latest/UserGuide/instance-types.html
VSI Results
Testing Configuration
Aws Citrix Xendesktop
For our testing purpose we provisioned a m4.2xlarge machine on EC2. This instance has a machine profile of 8 vCPU and 32 GB of memory. This is either running a XENO E5-2686 or 2676. Mostly a general use machine which is balanced.
Our testing configuration was 50 test users over the course of 48 minutes. We utilized the industry standard Knowledge Workload. This mostly presents a large portion of the VDI / SBC user base. Office application and standard office applications like Adobe Reader.
Application start times are all over the place for the most part, but staying for the most part under 12 seconds. Which would be reasonable for the users. Login process takes under 16 seconds even under VSI Max settings.
What does the backend look like?
When the CPU is at 100% the VSIMax is being reached within the user session. This means the numbers are indicating the bottleneck to be the CPU provisioned for the M4.2Xlarge instance which is approximately.
Wrap-up
Seeing is believing and after testing it I can confirm that Amazon EC2 is ready for the prime time. We were able to support 42 concurrent users on a M4.2Xlarge and we were able to have a continous level of excellent user experience while doing so.
Amazon is ready to supplement your traditional onpremise solutions with readily available and quickly scaleable resources in the cloud. Using Citrix Cloud services you can very easily scale your delivery out to support your user base as it dynamically changes.
Aws Citrix Vdi Login
Using VSI you can validate your configurations with support your users and put a check box next to user experience.
Using these three solutions you can future proof your company, and deliver on a promise of value & experience.
Finally, if you are looking for some testing for your deployment please reach out to me here or b.martynowicz@loginvsi.com.
As always stay tuned for more results.
